Smart Elevator, IoT layer

Elevator IoT hardware designed for your controllers.

A generic gateway reads voltage. It cannot tell you the car is at floor seven, that the door operator is drawing more current than it did in spring, or that the drive logged a fault two minutes before the callout. That takes an interface board built for the panel it lives in.

The problem

The panel is not a standard interface.

Two elevators in the same building can be five years apart in controller design. One publishes a clean serial frame with a documented register map. The next holds nothing but relay coils and a floor selector, and the only way to know the car is moving up is that a particular contactor is energised while another is not.

A universal IoT gateway handles neither case properly. It samples a few generic points, guesses at meaning, and produces a feed that looks like data and behaves like noise. Once that feed reaches a maintenance team, the credibility of the whole system goes with it.

The alternative is to survey the controller first and design the interface to what is really there. It is more engineering up front and far less argument later.

What the survey records

  • Controller make, model, and firmware revision per unit

  • Available signal points and whether they can be read safely

  • Panel voltages, free terminals, and physical space

  • Fault code table and how the controller reports it

  • Door operator type and its own control interface

  • Network options at the site, cellular coverage included

  • Whether the unit is in warranty and who holds it

Controller coverage

Four families, four different jobs.

How the hardware attaches to a lift depends entirely on what the controller is willing to say. These are the four cases that cover most elevators.

VVVF drives

Serial or fieldbus where the drive exposes one, plus discrete status lines

Modern variable frequency drives usually publish speed, current, and fault registers over a serial link. The interface reads the frame format the drive actually uses, which varies by manufacturer and by firmware revision within the same model line.

Relay logic panels

Isolated digital inputs across contactor and relay coils

Older panels hold no data bus at all. State has to be reconstructed from coil energisation, floor selector position, door operator contacts, and safety chain continuity. The board carries a wider input bank for this case.

Proprietary OEM boards

Vendor protocol decoded from a monitored bus or diagnostic port

Many OEM controllers expose a diagnostic connector intended for the manufacturer service tool. Where the electrical layer can be tapped safely and read only, the interface listens on it without participating in control traffic.

Mixed and older lifts

One hardware family, variant interface sections, per-controller firmware

Service companies rarely have one brand. The platform is designed so a single device family covers all your elevators, with the differences carried in the interface section and the firmware build rather than in five separate products.

Controller familyWhat the interface reads
VVVF drivesSerial or fieldbus registers, plus discrete status lines
Relay logic panelsIsolated digital inputs across contactor and relay coils
Proprietary OEM boardsVendor protocol read from a monitored diagnostic bus
Mixed and older liftsOne device family, variant sections, per-controller firmware
Interface section and firmware build change per family; the device family stays the same.

Edge device architecture

What is actually on the board.

The device is deliberately unglamorous. Its job is to read correctly, survive the panel, and never require a site visit to recover. Six blocks carry that.

Per-panel
Interface built to the controller in front of it
Read-only
Passive tap keeps the safety chain untouched
Retrofit
Fits existing panels and new units alike
OTA-ready
Fault tables and decoding update over the air

What the hardware captures

  • Car floor position and direction of travel
  • Door open, close, and full cycle time
  • Motor feed and door operator current
  • Controller fault codes with device timestamps
  • Run starts, completions, and trip counts
  • In-service and out-of-service state
01

Signal conditioning and isolation

Optocoupled digital inputs rated for the panel voltages actually present, with transient protection at the connector. Galvanic isolation keeps the elevator safety circuit and the measurement electronics electrically separate.

02

Analog and current sensing

Non-invasive current measurement on the motor feed and on the door operator, sampled fast enough to see the shape of a start rather than only an average. This is the input that later makes trend analysis possible.

03

Serial and bus interfaces

RS485, RS232, and CAN front ends configured per controller, with termination and biasing options set at build time so one board can be fitted to different panels without rework.

04

Edge compute

A microcontroller sized for continuous protocol decoding, event detection, and local storage, chosen for long-term availability rather than for the lowest unit price on the day of design.

05

Connectivity

Cellular for most retrofits, Ethernet where the building offers a stable drop, and Wi-Fi only where the site allows it. Antenna placement is planned for a metal panel inside a concrete shaft, which is a hostile radio environment.

06

Local storage and power handling

Non-volatile buffering so an outage does not create a gap in history, and a wide-range supply input with holdup so the device can report its own power loss before it goes down.

Send us the controller makes in your elevators. We will tell you what can be read from each one and how.

Book a technical assessment →

Design constraints

Built for a machine room, not a desk.

A prototype that works on a bench proves very little. The device has to hold up in a steel panel next to contactors that slam a few hundred times a day, in a room that nobody air-conditions, for the length of a service contract.

Component derating, conformal coating where the site needs it, connector choice that survives an installer in a hurry, and thermal margin are decided at design time. Field failures are expensive in a business where a truck roll is the unit of cost.

What the enclosure faces

  • Panel temperatures that sit well above ambient for years without a break

  • Continuous vibration and mechanical shock from the machine room floor

  • Switching noise from contactors and drive output stages on every trip

  • Dust and oil mist in machine rooms and shaft-mounted enclosures

  • Enclosure space measured in a few free DIN slots, not a rack

  • Sites that will not be revisited for years, so field access has to be remote

Retrofit and new install

Two paths onto your elevators.

Retrofit into existing elevators

The panel is surveyed before anything is designed: available voltages, free space, terminal access, and which signals can be read without touching the safety chain. The device is then built to fit inside that reality, with a wiring loom and a labelled terminal map so an installation is a repeatable job rather than an investigation.

Factory fit on new units

For OEMs the interface can move inside the panel design itself, sharing the controller supply and using a defined wiring loom. Serial numbers are assigned and paired to the unit on the production line, so a lift arrives on site already known to the platform.

Hardware is only half of it. The decoding, the fault mapping, and the update path live in the firmware. That side is covered on elevator embedded firmware.

Certification and production

Approval planned at schematic stage.

Compliance failures found at the test lab are respins, and respins are months. The layout, the filtering, and the isolation strategy are decided with the target approvals already on the table.

EMC

Emissions and immunity planned into the layout from the start, with filtering at every cable entry. A drive panel is one of the noisier places a small board can live, so immunity work matters as much as emissions.

Electrical safety and isolation

Creepage and clearance set for the mains-referenced sections, isolation barriers documented, and the interface designed so a fault on the device cannot propagate into elevator control wiring.

Radio approvals

Pre-certified cellular and radio modules used where possible to keep the approval scope on the host product rather than on the radio itself.

Production test

A functional test fixture and protocol defined with the board, so each unit is powered, exercised across every input, and serialised before it leaves the line.

FAQ

Questions about the hardware.

Elevator IoT hardware is the interface device installed in the lift control panel. It connects to the controller signal points, converts and isolates those signals, runs firmware that decodes them into structured events, and sends the result to a monitoring platform over cellular or Ethernet.

Start with a controller survey.

Every hardware decision follows from what your panels expose. Bring the list and we will give you a straight read on feasibility before anything is designed.
