THE CHALLENGEA Wagon Has No Onboard Power, So Every Report Costs Battery
A freight wagon has no engine, no alternator, and no harness to draw from, so a tracker has to live on its own primary cells for the life of the asset. A device that reports too often dies in months and strands a crew at the yard to change batteries across a whole fleet. A device that reports too rarely leaves you blind when a wagon is shunted, detached, or sitting idle accruing demurrage. The energy budget comes first, then the tracking is built around it, so a wagon reports often enough to be useful and still lasts years on a single lithium thionyl chloride pack.
Built within the Telematics and GPS Tracking ecosystem, and frequently paired with Railway Asset Monitoring.
WHAT'S INCLUDED
Self-Powered Wagon Tracker and Rake Logic
Multi-Year Self-Powered Tracker
The tracker is built around an STM32L low-power MCU and a lithium thionyl chloride primary battery pack so it runs for years with no vehicle power. The device sits in deep sleep most of its life and wakes only on a schedule or on motion, which is how a single pack stretches across the service interval of the wagon.
Accelerometer Wake and Deep Sleep
An accelerometer holds the device in microamp deep sleep until the wagon actually moves. A motion event wakes the MCU, takes a NavIC and GPS fix, and reports the change, then the device drops back to sleep. A parked wagon costs almost no battery, while a moving one is tracked closely.
NB-IoT and Cat-M1 Low-Power Reporting
A Quectel BG95 or BC660 modem runs on NB-IoT and Cat-M1 so each position report uses minimal energy and the device reaches deep into rail corridors and yards. Reports go out over MQTT or CoAP with small payloads, and power saving mode and eDRX are tuned so the radio sleeps between sends.
RFID Hybrid for Coverage-Poor Yards
Many yards sit indoors or in cellular and GNSS shadow, so the tracker is paired with passive RFID tags read by AEI readers at yard gates and weighbridges. When a wagon rolls past a reader its identity and time are logged even when the satellite tracker cannot see the sky, giving a continuous chain of custody.
Rake Formation and Consist Management
Individual wagons are grouped into the rake they are running in, with attach and detach events detected from shared motion, proximity, and gate reads. You see which wagons make up a consist, when one is dropped at a siding, and when a rake is reformed, so the manifest matches the metal on the rail.
Yard Geofences and Demurrage Tracking
Geofences are drawn around yards, sidings, loading points, and customer terminals, and the time each wagon dwells inside them is logged. The platform raises dwell and demurrage alerts so idle wagons accruing charges surface early instead of at month-end billing reconciliation.
HOW IT WORKS
From Motion Event to Rake Picture
Every stage is shaped by the energy budget. A wagon that moves is tracked closely, a wagon that sits is left asleep, and an RFID gate read fills the gap whenever the satellite tracker cannot reach a fix or a network.
Wake on Motion
The accelerometer wakes the STM32L from deep sleep when the wagon starts to move. FreeRTOS schedules the fix and report tasks, and the device stays awake only as long as the wagon is rolling.
Fix and Report
A u-blox NavIC and GPS receiver takes a position fix, and the Quectel NB-IoT or Cat-M1 modem sends a small MQTT or CoAP payload. Between reports the radio uses power saving mode so the battery budget holds for years.
Fuse and Form Rakes
The platform fuses satellite fixes with RFID gate reads, assigns each wagon to its rake, detects attach and detach, and runs geofence dwell timers for demurrage across the yard network.
STANDARDS AND COMPLIANCE
Built for Rail Environments and Long Field Life
IP67 and IP69K Enclosures
A wagon-mounted device faces rain, dust, washdown, and vibration for its whole life, so the enclosure is built to IP67 and IP69K sealing, with the mounting and potting designed to survive shunting shocks and the rail vibration spectrum.
NavIC and IRNSS Positioning
NavIC and IRNSS positioning runs alongside GPS, which improves fix reliability across Indian rail corridors and yards where regional augmentation helps the device get a usable fix faster on a tight power budget.
Battery Safety and Field Life
The lithium thionyl chloride pack is sized and qualified for the reporting profile, the deep sleep current draw is validated, and the multi-year battery budget is documented so replacement intervals are known and the fleet rollout is predictable.
FAQ
Common Questions
How long does the tracker last with no power from the wagon?
A wagon has no onboard power, so the device runs entirely on its own lithium thionyl chloride primary cells. Multi-year life comes from keeping the STM32L in microamp deep sleep, waking on accelerometer motion, and using NB-IoT or Cat-M1 with power saving mode so each report costs very little energy.
Why use an accelerometer to wake the device?
Most wagons spend long stretches parked. The accelerometer keeps the tracker asleep until the wagon actually moves, then wakes it to take a NavIC and GPS fix and report. This means a parked wagon barely touches the battery while a moving one is still tracked closely, which is how the pack lasts years.
How does RFID help in yards with poor coverage?
Indoor sheds and dense yards often block both GNSS and cellular. The satellite tracker is paired with passive RFID tags read by AEI readers at yard gates and weighbridges. When a wagon rolls past a reader its identity and time are logged, so you keep a continuous record even where the tracker cannot get a fix or a network.
How do you know which wagons form a rake?
Each wagon is assigned to a rake from shared motion patterns, proximity, and gate reads, with attach and detach detected when a wagon joins or leaves the consist. This keeps the running formation matched to the physical train so you can see when a wagon is dropped at a siding or a rake is reformed.
Can you track dwell time and demurrage in sidings?
Yes. Geofences are drawn around yards, sidings, loading points, and customer terminals, and the time each wagon stays inside is logged. The platform raises dwell and demurrage alerts so idle wagons accruing charges surface early instead of being discovered during month-end reconciliation.
Which network does the tracker use to report?
A Quectel BG95 or BC660 modem runs on NB-IoT and Cat-M1 because both are low power and reach deep into rail corridors and yards. Reports go out as small MQTT or CoAP payloads, and power saving mode and eDRX are tuned so the radio sleeps between sends to protect the battery budget.
Will the device survive the rail environment?
Yes. The enclosure is built to IP67 and IP69K so it handles rain, dust, and washdown, and the mounting and potting are designed to take shunting shocks and rail vibration. The battery and electronics are qualified for the temperature and vibration the wagon sees in service.
Ready to Build Your Wagon Tracking System?
Share your fleet size, your reporting interval, and the yards where coverage is poor to get a walkthrough of the energy budget, the RFID hybrid, and how multi-year battery life is achieved.
